BASE STATION VERTICAL ANTENNA
Xiegu VG4 antenna is a 4-band GP type and is made of aluminum alloy with anti-oxidation surface. It is light, solid, and easy to install. It is with good outdoor weather ability. After the normal installation without needing wind rope, it can resist strong wind up to about level 12 .
4-Band Vertical Antenna: VG4 is a 4-band GP type antenna and is made of aluminum alloy with an anti-oxidation surface, covering 40/20/15/10 meters. And this antenna can be adjusted to the frequency that we need.
Automatic band switching: Single coax cable feed, each band is individually tunable with wide VSWR bandwidth. Pin-point fine-tuning accuracy for rock-bottom SWR on any frequency you choose and with 100% automatic band selection.
No ground or radials needed: Effective counterpoise replaces radials. It is light and built to last and is easy to install and erect. Small area required for mounting, perfect for roofs, patios, small backyards, condos, and motorhome.
Top loading: Parallel resonators — best vertical-element efficiency. End loading of the lower HF bands allows efficient operation with a manageable antenna height.
Outdoor weather ability: The VG4 is high wind survival. After the normal installation, it can resist about level 12 strong wind. And it needs no wind cable for fastening.
SPECIFICATIONS:
Use frequency band: 7/14/21/28MHz (40m/20m/15m/10m)
Axial length: about 7.8m
Radial length: about 2.7m
Maximum power handling: 1000W PEP (CW500W, RTTY300W)
Antenna impedance: 50Ω
VSWR：＜1.5:1
Antenna bandwidth: 40m: 150kHz / 20m: 450kHz / 15m: 800kHz / 10m: 1000kHz
Rated wind speed: 35 m/s
Antenna interface type: SL16-K
Weight: about 7.0kg | 15.4lb
Package size: 13x13x120cm | 5.2×5.2x47in
Erection height: the distance from the ground is more than 3m
$269.00
target=”_blank” href=”https://radioddity.s3.amazonaws.com/Xiegu_VG4_Manual_EN_20220111.pdf” target=”_blank” rel=”noreferrer noopener”>CLICK HERE to download user manual.
