RFinder
In this video from Pacificon 2021, Bob Greenberg talks about his product, the RFinder B1 Plus, a digital radio that lets you talk from anywhere in the world to anywhere in the world, without ever needing a code plug!
DMRoIP to BrandMeister coming as a Software Update in the Near Future!
target=”_blank” href=”https://www.rfinder.net/docs/Rfinder-Android-Radio-Manual.pdf” target=”_blank” rel=”noreferrer noopener”>
RFinder B1-Plus – Advanced Users Guide – Click Here!
B1-Plus Specifications:
- Radio: 136-174, 400-490Mhz, FM Wide/Narrow, DMR Tier II
- Suitable Industry: Amateur Radio
Features:
- HT Transceiver: 4Watts DMR+Analog, VHF / UHF
- Selling Points: LTE 4G smartphone,IP67 rugged,PTT:DMR+UHF/DMR+VHF(optional),POC
- Display: 4.0 inch
- Touch Panel: 5 points capacitive screen,support rainwater operation,IPS.
- Resolution: 640 X 1136 Pixels TFT LCM
- Sim: Dual SIM,Dual standby ,the third SIM card for private network(Optional)
- Network: GSM, WCDMA, EVDO,TD-SCDMA,TDD/FDD-LTE
- Band:
- 2G GSM850/900/1800/1900;3G:WCDMA850/900/1900/2100
- LTE-FDD:B1/B2/B3/B4/B5/B7/B8/B17/B20
- LTE-TDD:B38/B39/B40/B41
- OS: Android 9.0
- CPU: MTK6765, Octa Core, 2.3GHz
- Memory: 4GB RAM + 64GB ROM
- Micro SD Card: Support up to 128GB
- Battery: target=”_blank” href=”mailto:2500mAh@7.4V”>2500mAh @ 7.4V (Standard)
- Color: Black
- Size: 148 x 64 x 30.3mm
- Weight: 430g
- SOS: Yes
- Channel Knob: Yes And Easy To Operate
- PTT: Optional, Push-to-Talk Over Two Way Radio
- POC: Yes, Push-to-Talk over Cellular/Wifi
- Programmable Key: Support,Customer Can Customize The Shortcut Key For Special Function By Software
- GNSS: GPS/BEIDOU/GLONASS
- Charging Dock: Yes
- Quick Charge: Supports 2A Quick Charge from Internal USB Port
- Belt Clip: Yes
- Internal Microphone: Yes, Dual Mic To Anti Noise
- IP Class: IP67
- Sensors: Gravity, Gyro, Distance Sensor, Light Sensor, 3D Accelerator, Pressure Sensor
- FM: Yes
- NFC: Optional, 13.56MHZ
- Speaker: 2 Watts
- Others: RoIP DMR enabled, In Development
- Camera: Front camera:5mega pixels / Rear camera:13mega pixels
- Picture Size: Up To 4096 X 3072 Pixels
- Flash LED/Torch: 1 Flash LED, 200 Lumina
- Video Record: 1920 X 1080 Recording,30fps
- External Camera: Supported, Optional
- External Hand Mic: Supported, Optional
- Data
- WLAN: WIFI 802.11 a/b/g/n, 2.4G/5.8G
- Data Port: USB 2.0
- USB Port: 20 Pin Multiple Port / 2A Charge Supports OTG
- OTG: Supported
- Bluetooth: BT4.0
Standard Accessories:
- Battery: 2500mAh@7.4V (Standard)
- Dual Band Antenna
- Data Cable
- Charger and Charger Adapter
- Belt Clip
- Laynard Strap
- Manual Foldout
